| According To | DIN913 DIN914-1980 | |||||||||
| DIN915 DIN916-1980 | ||||||||||
| Material | Alloy Steel | |||||||||
| Class of thread | 5g6g | |||||||||
| Surface Treatment | Black Oxide | |||||||||
| UNIT:mm | ||||||||||||||||||
| Thread Size (d) | Thread Pitch P | S | e | df | T | C | R | P | Z°25 | d | C | |||||||
| Nominal | Min. | Max. | Min. | Min. | Flat Point | Oval Point | Dog Point | Cone Point | Cup Point | |||||||||
| Max. | Min. | Max. | Short | Long | Max. | Max. | Min. | |||||||||||
| M3 | 0.50 | 1.5 | 1.520 | 1.545 | 1.73 | Minor Thread Dianeter | 2.0 | 2.0 | 1.75 | 2.5 | Dinmension is the same as the Flat Point | 0.75 | 1.5 | 0.5 | 1.4 | 1.15 | ||
| M4 | 0.70 | 2.0 | 2.020 | 2.045 | 2.30 | 2.5 | 2.5 | 2.25 | 3.0 | 1.00 | 2.0 | 0.7 | 2.0 | 1.75 | ||||
| M5 | 0.80 | 2.5 | 2.520 | 2.560 | 2.87 | 3.0 | 3.5 | 3.20 | 4.0 | 1.25 | 2.5 | 0.8 | 2.5 | 2.25 | ||||
| M6 | 1.00 | 3.0 | 3.020 | 3.080 | 3.44 | 3.5 | 4.0 | 3.70 | 5.0 | 1.50 | 3.0 | 1.5 | 3.0 | 2.75 | ||||
| M8 | 1.25 | 4.0 | 4.020 | 4.095 | 4.58 | 5.0 | 5.5 | 5.20 | 7.0 | 2.00 | 4.0 | 2.0 | 5.0 | 4.70 | ||||
| M10 | 1.50 | 5.0 | 5.020! | 5.095 | 5.72 | 6.0 | 7.0 | 6.64 | 9.0 | 2.50 | 5.0 | 2.5 | 6.0 | 5.70 | ||||
| M12 | 1.75 | 6.0 | 6.020 | 6.095 | 6.86 | 8.0 | 8.5 | 8.14 | 11.0 | 3.00 | 6.0 | 3.0 | 8.0 | 7.64 | ||||
| M14 | 2.00 | 6.0 | 6.020 | 6.095 | 6.86 | 9.0 | 10.0 | 9.64 | 13.0 | 3.50 | 7.0 | 4.0 | 9.0 | 8.64 | ||||
| M16 | 2.00 | 8.0 | 8.025 | 8.115 | 9.15 | 10.0 | 12.0 | 11.57 | 15.0 | 4.00 | 8.0 | 4.0 | 10.0 | 9.64 | ||||
Mechanical Property | Class of Property | Metric Diameter of Thread d | Test Min Length of Bolt | mm | Ensure Torque Nm | Socket Screw Keys mm | ||||||||||
| 14H | 22H | 33H | 45H | Flat | Wimber | Column | Concave | |||||||||
| HV10 | Min. | 140 | 220 | 330 | 450 | |||||||||||
| 3 | 4 | 5 | 6 | 5 | 0.9 | 1.5 | ||||||||||
| Max. | 290 | 300 | 440 | 560 | 4 | 5 | 6 | 8 | 6 | 2.5 | 2 | |||||
F=30D2 | Min. | 133 | 209 | 314 | 428 | |||||||||||
| Max. | 276 | 285 | 418 | 532 | 5 | 6 | 8 | 8 | 6 | 5 | 2.5 | |||||
| Rockwell hardness | Min. | Min. | 75 | 95 | 一 | 6 | 8 | 8 | 10 | 8 | 8.5 | 3 | ||||
| Max. | 105 | 2) | 一 | 8 | 10 | 10 | 12 | 10 | 20 | 4 | ||||||
| HRC | Min. | 一 | 2) | 33 | 45 | 10 | 12 | 12 | 16 | 12 | 40 | 5 | ||||
| Max. | 一 | 30 | 44 | 53 | 12 | 16 | 16 | 20 | 16 | 65 | 6 | |||||
| Ensure torque | 一 | See side table | ||||||||||||||
| 16 | 20 | 20 | 25 | 20 | 160 | 8 | ||||||||||
| Emin | 1/2H1 | 2/3H1 | 3/4H1 | |||||||||||||
| Gmax,mm | 0.015 | 0.015 | 3) | 20 | 25 | 25 | 30 | 25 | 310 | 10 | ||||||
| HV0.3 max | - | 320 | 450 | 580 | 24 | 30 | 30 | 35 | 30 | 520 | 12 | |||||
Pengchi Hardware (shandong) Co., Ltd. passed ISO9001:2008 quality management system certification, and actively prepared TS16949 quality system certification. At the same time, the company, in accordance with the requirements of national laboratory standards, is equipped with a full set of imported fastener quality testing instruments and professionals to strictly control and test the raw material procurement, finish milling, production and manufacturing, heat treatment, packaging and shipment and other processes. Ensure that each "XGP" screw can meet the technical standard requirements.
We own cold heading machines, hot heading machines, CNC lathes, CNC machining centers, and punching machines. With over a decade of experience, we have a team of over 30 people, including over 10 professional technicians. We utilize domestically produced high-tech equipment and regularly update it. Our extensive production experience and advanced technology make us a trusted source of expertise.
